Definition

Water consumption and process utility calculations in Oral Solid Dosage (OSD) manufacturing involve estimating purified water, compressed air, and steam requirements based on batch size, equipment design, process parameters, and cleaning operations. Accurate utility calculations support GMP compliance, efficient production planning, and optimized operating costs.

---

Pharmaceutical manufacturing facilities rely heavily on utilities to ensure smooth, compliant, and efficient operations. In Oral Solid Dosage (OSD) manufacturing, purified water, compressed air, and steam are among the most critical utilities supporting production, cleaning, environmental control, and equipment operation.

Whether manufacturing tablets through direct compression or wet granulation, understanding utility demand is essential for facility design, capacity planning, cost optimization, and regulatory compliance.

This guide explains the key formulas, calculation methods, practical examples, and GMP considerations for estimating utility requirements in OSD facilities.

---

Why Utility Calculations Matter in OSD Manufacturing

Accurate utility calculations help manufacturers:

• Prevent production interruptions
• Size utility systems correctly
• Reduce operational costs
• Improve equipment performance
• Support cleaning validation activities
• Meet regulatory expectations
• Optimize energy consumption

Utilities typically account for a significant portion of pharmaceutical operating expenses, making precise estimation a critical engineering and manufacturing activity.

---

Major Utilities Used in OSD Manufacturing

Utility	Typical Application
Purified Water (PW)	Granulation, CIP, equipment cleaning
Compressed Air	Pneumatic controls, tablet presses, dedusters
Clean Steam	SIP systems, vessel heating, sterilization
HVAC Utilities	Environmental control
Electricity	Equipment operation

This article focuses on purified water, compressed air, and clean steam calculations.

---

Purified Water Usage Calculations

Purified water is extensively used during:

• Wet granulation processes
• Binder solution preparation
• Equipment cleaning
• CIP operations
• Final rinsing

---

Purified Water for Wet Granulation

Formula

$$W_{water}=B_{size}\times P_{ratio}\times M_{ratio}$$Wwater​=Bsize​×Pratio​×Mratio​

Where:

Parameter	Description
Wwater	Water required (kg)
Bsize	Dry batch size (kg)
Pratio	Binder spray percentage
Mratio	Moisture ratio

Example Calculation

Given

• Batch size = 500 kg
• Binder spray = 20%
• Moisture ratio = 40%

Calculation

$$W_{water} = 500 \times 0.20 \times 0.40$$Wwater​=500×0.20×0.40 $$= 40kg$$=40kg

Result

Purified water required:

40 kg (approximately 40 liters)

---

Typical Water Usage in Wet Granulation

Process	Water Requirement
Low Moisture Granulation	5–10%
Standard Wet Granulation	10–20%
High Moisture Granulation	20–30%

CIP and Equipment Rinse Water Calculations

Water consumption during cleaning depends on:

• Equipment size
• Surface area
• Spray nozzle flow rate
• Number of rinse cycles

---

Formula

$$Water\ Usage= Surface\ Area \times Water\ Rate$$Water Usage=Surface Area×Water Rate

---

Example

Given

• Equipment internal surface area = 25 m²
• Water usage rate = 2.5 L/m²

Calculation

$$25 \times 2.5 = 62.5L$$25×2.5=62.5L

Result

Water required per rinse cycle:

62.5 liters

---

Typical Pharmaceutical CIP Water Consumption

Cleaning Stage	Water Usage
Pre-Rinse	1.5–3 L/m²
Detergent Wash	2–4 L/m²
Final Rinse	1.5–3 L/m²

Compressed Air Estimation

Compressed air is essential for:

• Pneumatic valves
• Tablet presses
• Capsule fillers
• Product transfer systems
• Air purging
• Dust removal

Pharmaceutical compressed air must meet strict quality standards including:

• Oil-free supply
• Low microbial load
• Pressure dew point of approximately -40°C

---

Compressed Air Demand Formula

$$Q_{total} = (\sum q_{valve}\times n\times UF) + Q_{process}$$Qtotal​=(∑qvalve​×n×UF)+Qprocess​

Where:

Parameter	Description
qvalve	Air consumed per valve cycle
n	Number of valves/cylinders
UF	Usage factor
Qprocess	Continuous process airflow

Example Calculation

Given

Tablet press requires:

• Continuous airflow = 80 m³/hr

Pneumatic system:

• 40 cylinders
• 15 cycles/min
• 0.05 m³ per cycle
• Usage factor = 0.5

Calculation

$$Q_{valves} = 0.05\times40\times15\times60\times0.5$$Qvalves​=0.05×40×15×60×0.5 $$= 900m^3/hr$$=900m3/hr

Total demand:$$Q_{total} = 900+80 = 980m^3/hr$$Qtotal​=900+80=980m3/hr

Result

Compressed air demand:

980 m³/hr

---

Compressed Air Consumption by Equipment

Equipment	Typical Air Demand
Tablet Press	50–150 m³/hr
Capsule Filler	30–100 m³/hr
Pneumatic Conveying	100–500 m³/hr
Dust Collector Pulse Jet	20–200 m³/hr

Steam Consumption Calculations

Clean steam is commonly used for:

• Sterilization-In-Place (SIP)
• Vessel sterilization
• Jacket heating
• Steam sanitization
• Pure steam generators

---

Steam Consumption Formula

Step 1: Calculate Heat Load

$$Q=m\times c_p\times \Delta T$$Q=m×cp​×ΔT

Where:

Parameter	Description
m	Mass (kg)
cp	Specific heat capacity
ΔT	Temperature change

Step 2: Calculate Steam Requirement

$$m_{steam} = \frac{Q_{load}}{h_{fg}}$$msteam​=hfg​Qload​​

Where:

Parameter	Description
msteam	Steam required (kg/hr)
Qload	Total heat load (kJ/hr)
hfg	Latent heat of steam

Example Calculation

Given

Granulator bowl:

• Weight = 200 kg
• Cp = 0.5 kJ/kg°C

Wet mass:

• Weight = 50 kg
• Cp = 4.18 kJ/kg°C

Temperature:

• Initial = 25°C
• Final = 121°C

Heat load:$$60,000kJ/hr$$60,000kJ/hr

Latent heat:$$h_{fg} = 2201kJ/kg$$hfg​=2201kJ/kg

Calculation

$$m_{steam} = \frac{60000}{2201}$$msteam​=220160000​ $$= 27.2kg/hr$$=27.2kg/hr

Result

Required steam:

27.2 kg/hr

---

Typical Steam Consumption in OSD Facilities

Application	Steam Consumption
SIP Systems	20–100 kg/hr
Fluid Bed Dryer Heating	50–300 kg/hr
Granulator Jacket Heating	10–80 kg/hr
Pure Steam Generator	100–1000 kg/hr

Utility Demand Planning for OSD Facilities

When sizing utility systems, engineers should account for:

Simultaneous Equipment Operation

Not all equipment operates simultaneously.

Use diversity factors:

• 60–80% for production
• 30–60% for pneumatic systems

---

Peak Demand

Design systems based on:

• Peak production periods
• Cleaning schedules
• Utility redundancy requirements

---

Future Expansion

Industry practice typically includes:

• 20–30% spare capacity

---

Step-by-Step Utility Calculation Method

Step 1: Define Production Capacity

Determine:

• Batch size
• Product type
• Annual production volume

Step 2: Identify Utility Consumers

List:

• Granulators
• Tablet presses
• CIP systems
• HVAC equipment

Step 3: Gather Equipment Data

Collect:

• Water consumption
• Air demand
• Steam requirements

Step 4: Calculate Utility Loads

Apply engineering formulas.

Step 5: Apply Usage Factors

Consider simultaneous operation.

Step 6: Determine Peak Load

Calculate maximum expected demand.

Step 7: Add Safety Margin

Include future expansion allowance.

Step 8: Verify Against GMP Requirements

Ensure compliance with pharmaceutical standards.

---

GMP and Regulatory Considerations

Utility systems are subject to stringent regulatory oversight.

Relevant guidance includes:

• FDA Guide to Inspections of High Purity Water Systems
• WHO GMP for Water for Pharmaceutical Use
• EU GMP Annex 1
• ISPE Baseline Guides
• PIC/S GMP Guidance

---

Purified Water Requirements

Manufacturers should validate:

• Conductivity
• TOC
• Microbial limits
• Distribution loop performance

---

Compressed Air Requirements

Compressed air systems should be monitored for:

• Particulates
• Oil contamination
• Moisture content
• Microbial contamination

---

Steam System Requirements

Clean steam systems should demonstrate:

• Condensate quality
• Sterility
• Non-condensable gas control
• Pressure consistency

ystem sizing, GMP compliance, and cost-effective operations.

Frequently Asked Questions (FAQs)

1. Why is purified water used in OSD manufacturing?

Purified water is primarily used for wet granulation, cleaning, CIP systems, and equipment rinsing.

2. How do you calculate water required for granulation?

Use the formula: Batch Size × Binder Spray Ratio × Moisture Ratio.

3. What is compressed air used for in tablet manufacturing?

It powers pneumatic valves, tablet presses, dedusters, and conveying systems.

4. What quality standards apply to pharmaceutical compressed air?

Compressed air must be dry, oil-free, and microbiologically controlled.

5. How is steam consumption calculated?

Steam requirement equals total heat load divided by latent heat of vaporization.

6. What is clean steam?

Clean steam is pharmaceutical-grade steam used for sterilization and sanitary applications.

7. Why are utility calculations important?

They ensure proper system sizing, GMP compliance, and cost-effective operations.

8. What is a diversity factor in utility design?

It accounts for equipment not operating simultaneously.

9. How often should utility systems be validated?

According to risk assessment, periodic review schedules, and regulatory expectations.

10. Which regulations govern pharmaceutical utility systems?

FDA, WHO GMP, EU GMP, PIC/S, and ISPE guidelines.
